Minimum order quantities apply on all of our products Please get in touch to see how we can support you on your next Power Supply Application project.
The DYS602-300216W-RS is a Single output 30V DC 2.16A 64.8W model, and delivers quality output expected from a professional-grade power supply unit. The 15DYS602-xyW-RS Series is a high-quality and reliable 60W AC/DC External Desktop Power Supply (PSU) . Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47-63Hz. Certified to UKCA, CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 60950-1/IEC 60950-1/UL 60950-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | Product Clearance Desktop Power Supply |
---|---|
Input Voltage | 90~264V AC |
Output | 30V DC 2.16A |
Output Power | 64.8W |
Number of Outputs | Single |
Efficiency | 88.0% |
Output Connector | 2.1 x 5.5 x 12 mm |
Dimensions | 120x52.5x32mm |
Industry | ITE, Audio & Video |
Standards | EN 60950-1, IEC 60950-1, UL 60950-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
15DYS602-120500W-RS | 12V DC | 5A | 60W | Download Pdf | |
Compare |
15DYS602-240270W-RS | 24V DC | 2.7A | 64.8W | Download Pdf | |
Compare |
15DYS602-180361W-RS | 18V DC | 3.61A | 65W | Download Pdf |
![]() |
Rapid | Product Code: 144-0985 |
