AC/DC External Desktop Power Supply 66JYH32-2402700-RS

The JYH32-2402700-RS is a Single output 24 2.7A 64.8W model, and delivers quality output expected from a professional-grade power supply unit. The 66JYH32-xy-RS Series is a high-quality and reliable 65W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a IEC C14 input connection and supports input voltages of 100~240V AC 47~63Hz. Certified to UKCA, CE, CB, cULus, TUV-GS, PSE, FCC, RoHS and compliant with EN 60950-1/UL 60950-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, CB, cULus, TUV-GS, PSE, FCC, RoHS
Class I (C14)
Meets Efficiency Level VI & (EU) 2019/1782
Single Output 24~48V DC
UL/EN 60950-1 Safety Approved
Universal Input 100~240V AC

Basic Specification

Product Type	Product Clearance Desktop Power Supply
Input Voltage	100~240V AC
Output	24V DC 2.7A
Output Power	64.8W
Number of Outputs	Single
Efficiency	88.0%
Output Connector	2.1 x 5.5 x 11 mm
Dimensions	120x53x32mm
Industry	ITE, Audio & Video
Standards	EN 60950-1, UL 60950-1
