AC/DC External Desktop Power Supply 15DYS602-180361W-RS

15DYS602-180361W-RS
15DYS602-180361W-RS

The DYS602-180361W-RS is a Single output 18V DC 3.61A 64.98W model, and provides the control needed for precision power tasks. The 15DYS602-xyW-RS Series is a high-quality and reliable 60W AC/DC External Desktop Power Supply (PSU) . Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47-63Hz. Certified to UKCA, CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 60950-1/IEC 60950-1/UL 60950-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, cULus, RCM (C-Tick), RoHS & REACH
  • Class II IEC C8 Connector
  • DoE Level VI Efficiency
  • Limited Power Source (LPS)
  • OVP, OCP, SCP
  • UL/IEC/EN 60950-1 Safety Approved
  • Universal Input 90~264V AC

Basic Specification

Product Type Product Clearance Desktop Power Supply
Input Voltage 90~264V AC
Output 18V DC 3.61A
Output Power 65W
Number of Outputs Single
Efficiency 88.0%
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 120x52.5x32mm
Industry ITE, Audio & Video
Standards EN 60950-1, IEC 60950-1, UL 60950-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
15DYS602-120500W-RS
15DYS602-120500W-RS
12V DC 5A 60W Download Pdf
Compare
15DYS602-240270W-RS
15DYS602-240270W-RS
24V DC 2.7A 64.8W Download Pdf
Compare
15DYS602-300216W-RS
15DYS602-300216W-RS
30V DC 2.16A 64.8W Download Pdf
