AC/DC External Desktop Power Supply 15DYS602-180361W

The DYS602-180361W is a Single output 18V DC 3.61A 64.98W model, and offers clean, regulated power in demanding environments. The 15DYS602-xyW Series is a reliable and efficient 65W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as telecoms, computing and multimedia systems.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, RCM (C-Tick), RoHS and compliant with IEC 60950-1/UL 60950-1/EN 60950-1 . This product range is built for integration into complex electronic environments - browse compatible options. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, (C-Tick), RoHS
IEC/UL/EN 60950-1 Safety Approved
Meets Efficiency Level VI
OVP, OCP, SCP
Single Output 12V DC
Universal Input 90~264V AC

Basic Specification

Product Type	Product Clearance Desktop Power Supply
Input Voltage	90~264V AC
Output	18V DC 3.61A
Output Power	65W
Number of Outputs	Single
Efficiency	88.0%
Output Connector	2.1 x 5.5 x 12 mm
Dimensions	120x52.5x32mm
Industry	ITE, Audio & Video
Standards	IEC 60950-1, UL 60950-1, EN 60950-1
