12W Constant Voltage LED Driver56YSL12F-xy-zzW Series

The 56YSL12F-xy-zzW Series is a versatile and energy-saving 12W Constant Voltage LED Driver. Designed for use in applications such as general-purpose LED lighting across commercial settings.. This series is supplied with a Terminal Block input connection and supports input voltages of 220~240V AC 47~63Hz. Certified to TUV-GS, RoHS, REACH and compliant with IEC 61347-1/IEC 61347-2-13. This product range is suitable for demanding LED integration in high-usage environments. If you can’t find what you need, contact us for alternative or tailored options.

Features

Class II Protection Design
Constant Voltage (CV)
Flicker-free Design
Input Voltage Range 220~240V AC
IP20
Protection OVP, OLP, SCP
Ultrathin Design
Working Temperature -20°C ~ +45°C

Basic Specification

Product Type	LED Drivers Constant Voltage (CV)
Input Voltage	220~240V AC 47~63Hz
Output Power	12W
Number of Outputs	Single
Input Connection	Terminal Block
Dimensions	127x50x12mm
Industry	LED Lighting
Standards	IEC 61347-1, IEC 61347-2-13

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSL12F-1200500	12V DC	0.5A	6W	Download Pdf
Compare	56YSL12F-2402500	24V DC	0.25A	6W	Download Pdf
Compare	56YSL12F-1201000	12V DC	1A	12W	Download Pdf
Compare	56YSL12F-2400500	24V DC	0.5A	12W	Download Pdf
