Home / LED Drivers / Dimmable / 56YSL100D-xy / 56YSL100D-3601380

Add to shortlist

Compare

Triac Dimming (CV) LED Driver56YSL100D-3601380

The YSL100D-3601380 is a Single output 36V DC 1.38A 49.68W model, and delivers high compatibility with OEM build specs. The 56YSL100D-xy Series is a efficient and reliable 100W Triac Dimming (CV) LED Driver. Designed for use in applications such as signage, retail and architectural lighting installations.. This series is supplied with a Terminal Block input connection and supports input voltages of 220~240V AC 47~63Hz. Certified to UKCA, CE, CB, RCM (C-Tick), TUV-GS, cURus, RoHS, REACH and compliant with IEC 61347-1/IEC 61347-2-13. This product range has been developed for long-term use in integrated lighting systems. If you can’t find what you need, contact us for alternative or tailored options.

Features

Class II Protection Design
Constant Voltage
Input Voltage Range 100-240VAC/200-240VAC
Protection OVP, OLP, SCP
Triac Dimming
Working Temperature -20°C ~ +50°C

Basic Specification

Product Type	LED Drivers Dimmable
Input Voltage	100~240V AC
Output	36V DC 1.38A
Output Power	49.7W
Number of Outputs	Single
Efficiency	89%
Output Connector	Terminal Block
Dimensions	180x66x32mm
Industry	LED Lighting
Standards	IEC 61347-1, IEC 61347-2-13

Pdf Spec Sheet

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSL100D-1204160	12V DC	4.16A	49.9W	Download Pdf
Compare	56YSL100D-2402080	24V DC	2.08A	49.9W	Download Pdf
Compare	56YSL100D-4801040	48V DC	1.04A	49.9W	Download Pdf
