Home / LED Drivers / Constant Voltage (CV) / 56YSL80-xy / 56YSL80-1206670

Add to shortlist

Compare

Constant Voltage (IP20) LED Driver56YSL80-1206670

The YSL80-1206670 is a Single output 12V DC 6.67A 80.04W model, and delivers high compatibility with OEM build specs. The 56YSL80-xy Series is a stable and lighting-compatible 80W Constant Voltage (IP20) LED Driver. Designed for use in applications such as indoor, retail and exterior lighting setups.. This series is supplied with a Terminal Block input connection and supports input voltages of 220~240V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, RoHS, REACH and compliant with IEC 61347-1/IEC 61347-2-13. This product range has been designed to support efficient performance across lighting networks. If you can’t find what you need, contact us for alternative or tailored options.

Features

Class II Protection Design
Constant Voltage
Input Voltage Range 220~240V AC
Protection OVP, OLP, SCP
Working Temperature -20°C ~ +45°C

Basic Specification

Product Type	LED Drivers Constant Voltage (CV)
Input Voltage	220~240V AC
Output	12V DC 6.67A
Output Power	80W
Number of Outputs	Single
Efficiency	90%
Output Connector	Terminal Block
Dimensions	170x57x32mm
Industry	LED Lighting
Standards	IEC 61347-1, IEC 61347-2-13

Pdf Spec Sheet

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSL80-4801660	18V DC	1.66A	29.9W	Download Pdf
Compare	56YSL80-2403330	24V DC	3.33A	79.9W	Download Pdf
Compare	56YSL80-3602220	36V DC	2.22A	79.9W	Download Pdf
