125W Open Frame Chassis AC/DC Power Supply Module43TAD125-USxy Series

The 43TAD125-USxy Series is a versatile and reliable 125W Open Frame Chassis AC/DC Power Supply Module. Designed for use in applications such as automation and control within IT and AV systems.. This series is supplied with a Open Frame input connection and supports input voltages of 85~264V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is optimised for modern electronic designs - check out the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, CB, cURus, FCC, RoHS & REACH
EN/IEC/UL 62368-1 Safety Approved
High-Efficiency Rating up to 92%
Operating ambient temperature range: -40°C ~ +85°C
Output Voltage 12~48V DC
Universal Input 85~264V AC

Basic Specification

Product Type	Internal Power Supply (PSU) Open Frame Chassis Power Supplies
Input Voltage	85~264V AC 47~63Hz
Output Power	125W
Number of Outputs	Single
Input Connection	Open Frame
Isolation	3000V AC
Dimensions	3.04x2.01x0.1"
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	43TAD125US12B	12V DC	8.34A	100.1W	Download Pdf
Compare	43TAD125US15B	15V DC	6.67A	100.1W	Download Pdf
Compare	43TAD125US18B	18V DC	5.56A	100.1W	Download Pdf
Compare	43TAD125US24B	24V DC	4.17A	100.1W	Download Pdf
Compare	43TAD125US36B	36V DC	2.78A	100.1W	Download Pdf
Compare	43TAD125US28B	28V DC	3.58A	100.2W	Download Pdf
Compare	43TAD125US48B	48V DC	2.09A	100.3W	Download Pdf
