65W Enclosed AC/DC Power Supply (PSU)43TED65-P-USxy Series

43TED65-P-USxy

The 43TED65-P-USxy Series is a performance-focused 65W Enclosed AC/DC Power Supply (PSU). Designed for use in applications such as network equipment and signal distribution hardware.. This series is supplied with a Metal input connection and supports input voltages of 85~265V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is suited for embedded use across IT, audio and visual sectors—view related products. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, CB, cURus, FCC, RoHS & REACH
  • EN/IEC/UL 62368-1 Safety Approved
  • High-Efficiency Rating up to 93.5%
  • Operating ambient temperature range: -40°C ~ +85°C
  • Single Output Voltage
  • Universal Input 85~264V AC

Basic Specification

Product Type Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage 85~265V AC 47~63Hz
Output Power 65W
Number of Outputs Single
Input Connection Metal
Isolation 3000V AC
Dimensions 3.53x2.38x1.31"
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
43TED65US05C-P
43TED65US05C-P
5V DC 10A 50W Download Pdf
Compare
43TED65US12C-P
43TED65US12C-P
12V DC 5.42A 65W Download Pdf
Compare
43TED65US241C-P
43TED65US241C-P
24V DC 2.71A 65W Download Pdf
Compare
43TED65US24C-P
43TED65US24C-P
24V DC 2.71A 65W Download Pdf
Compare
43TED65US7P5C-P
43TED65US7P5C-P
7.5V DC 8.67A 65W Download Pdf
Compare
43TED65US15C-P
43TED65US15C-P
15V DC 4.34A 65.1W Download Pdf
Compare
43TED65US09C-P
43TED65US09C-P
9V DC 7.23A 65.1W Download Pdf
Compare
43TED65US18C-P
43TED65US18C-P
18V DC 3.62A 65.2W Download Pdf
Compare
43TED65US281C-P
43TED65US281C-P
28V DC 2.33A 65.2W Download Pdf
Compare
43TED65US28C-P
43TED65US28C-P
28V DC 2.33A 65.2W Download Pdf
Compare
43TED65US36C-P
43TED65US36C-P
36V DC 1.81A 65.2W Download Pdf
Compare
43TED65US48C-P
43TED65US48C-P
48V DC 1.36A 65.3W Download Pdf
Compare
43TED65US53C-P
43TED65US53C-P
53V DC 1.24A 65.7W Download Pdf
