30W DIN Rail Mount AC/DC Power Supply Converter56YSD30S-xy-RS Series

The 56YSD30S-xy-RS Series is a high-quality and reliable 30W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.

Features

Output Voltages: 5~24V DCIEC/UL/EN 60950-1Meets the latest Safety Standards and ApprovalsHigh-Efficiency100% Full load burn-in TestLow Ripple & NoiseClass?Protection: Overload/Over voltage/Short circuit
Universal Input 90~264V AC 50/60Hz

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC 47~63Hz
Output Power	30W
Number of Outputs	Single
Input Connection	Screw Terminal Block
Isolation	500V DC
Dimensions	58x35x90mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSD30S-0503000-RS	5V DC	3A	15W	Download Pdf
Compare	56YSD30S-1202500-RS	12V DC	2.5A	30W	Download Pdf
Compare	56YSD30S-2401250-RS	24V DC	1.25A	30W	Download Pdf
