30W DIN Rail Mount AC/DC Power Supply Converter56YSD30S-xy Series

The 56YSD30S-xy Series is a high-efficiency and standards-compliant 30W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as industrial control and automation systems.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, CB, cULus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is perfect for manufacturers requiring efficient and adaptable power units. If you can’t find what you need, contact us for alternative or tailored options.

Features

3 Years Warranty
Class II Isolation
High-Efficiency
Protection: OLP, OVP, SCP
Ultra Slim Step Line
Universal Input 90~264V AC

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC 47~63Hz
Output Power	30W
Number of Outputs	Single
Input Connection	Screw Terminal Block
Isolation	500V DC
Dimensions	58x35x90mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSD30S-0503000	5V DC	3A	15W	Download Pdf
Compare	56YSD30S-1202500	12V DC	2.5A	30W	Download Pdf
Compare	56YSD30S-1502000	15V DC	2A	30W	Download Pdf
Compare	56YSD30S-2401250	24V DC	1.25A	30W	Download Pdf
