Check out our range of power conversion series suitable for a vast range of commercial applications.
Compare
15W DIN Rail Mount AC/DC Power Supply Converter56YSD15S-xy-RS Series
The 56YSD15S-xy-RS Series is a regulated and reliable 15W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as system-critical media and control infrastructure.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 50~60Hz. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is ideal for system builders and engineers - get in touch for technical support. If you can’t find what you need, contact us for alternative or tailored options.
Features
- 100% Full load burn-in Test
- Class?
- High-Efficiency
- IEC/UL/EN 60950-1
- Low Ripple & Noise
- Meets the latest Safety Standards and Approvals
- Output Voltages: 5~24V DC
- Protection: Overload/Over voltage/Short circuit
- Universal Input 85~264V AC / 120~370 V DC 50/60Hz
Basic Specification
| Product Type | Internal Power Supply (PSU) DIN Rail Power Supplies |
|---|---|
| Input Voltage | 90~264V AC 50~60Hz |
| Output Power | 15W |
| Number of Outputs | Single |
| Input Connection | Screw Terminal Block |
| Isolation | 500V DC |
| Dimensions | 58x18x90mm |
| Industry | ITE, Audio & Video |
| Standards | EN 62368-1, IEC 62368-1, UL 62368-1 |
Models in this series
| Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
|---|---|---|---|---|---|---|
Compare |
56YSD15S-0502400-RS | |
5V DC | 2.4A | 12W | Download Pdf |
Compare |
56YSD15S-4800310-RS | |
48V DC | 0.31A | 14.9W | Download Pdf |
Compare |
56YSD15S-1201250-RS | |
12V DC | 1.25A | 15W | Download Pdf |
Compare |
56YSD15S-2400630-RS | |
24V DC | 0.63A | 15.1W | Download Pdf |
Need help deciding on this power supply unit?
Our sales and technical team are just a click away.
