125W DIN Rail Mount AC/DC Power Supply Converter43TDD125-USxy Series

43TDD125-USxy
43TDD125-USxy

The 43TDD125-USxy Series is a high-efficiency and standards-compliant 125W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as industrial control and automation systems.. This series is supplied with a Pin Connection input connection and supports input voltages of 85~264V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is perfect for manufacturers requiring efficient and adaptable power units. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, CB, cURus, FCC, RoHS & REACH
  • EN/IEC/UL 62368-1 Safety Approved
  • High-Efficiency Rating up to 92%
  • Operating ambient temperature range: -40°C ~ +85°C
  • Output Voltage 12~48V DC
  • Universal Input 85~264V AC

Basic Specification

Product Type Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage 85~264V AC 47~63Hz
Output Power 125W
Number of Outputs Single
Input Connection Pin Connection
Isolation 3000V AC
Dimensions 1.97x1.77x1.54"
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
43TDD125US12B
43TDD125US12B
12V DC 8.34A 100.1W Download Pdf
Compare
43TDD125US15B
43TDD125US15B
15V DC 6.67A 100.1W Download Pdf
Compare
43TDD125US18B
43TDD125US18B
18V DC 5.56A 100.1W Download Pdf
Compare
43TDD125US24B
43TDD125US24B
24V DC 4.17A 100.1W Download Pdf
Compare
43TDD125US36B
43TDD125US36B
36V DC 2.78A 100.1W Download Pdf
Compare
43TDD125US28B
43TDD125US28B
28V DC 3.58A 100.2W Download Pdf
Compare
43TDD125US48B
43TDD125US48B
48V DC 2.09A 100.3W Download Pdf
