Chassis Mount AC/DC Power Supply Converter43TUF150US36B

43TUF150US36B

The TUF150US36B is a Single output 36V DC 4.17A 150.12W model, and offers a steady output ideal for continuous-use systems. The 43TUF150-USxy Series is a regulated and reliable 150W Chassis Mount AC/DC Power Supply Converter. Designed for use in applications such as system-critical media and control infrastructure.. This series is supplied with a Metal input connection and supports input voltages of 85~264V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is ideal for system builders and engineers - get in touch for technical support. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, CB, cURus, FCC, RoHS & REACH
  • EN/IEC/UL 62368-1 Safety Approved
  • External Fan option available on 43TEF & 43TDF products
  • High-Efficiency Rating up to 92.5%
  • Operating ambient temperature range: -40°C ~ +85°C
  • Output Voltage 12~48V DC
  • Universal Input 85~264V AC

Basic Specification

Product Type Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage 85~264V AC
Output 36V DC 4.17A
Output Power 150.12W
Number of Outputs Single
Efficiency 92.0%
Output Connector Pin Connection
Dimensions 4.6x2.44x1.54 "
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
43TUF150US12B
43TUF150US12B
12V DC 12.5A 150W Download Pdf
Compare
43TUF150US15B
43TUF150US15B
15V DC 10A 150W Download Pdf
Compare
43TUF150US24B
43TUF150US24B
24V DC 6.25A 150W Download Pdf
Compare
43TUF150US28B
43TUF150US28B
28V DC 5.36A 150.08W Download Pdf
Compare
43TUF150US48B
43TUF150US48B
48V DC 3.13A 150.24W Download Pdf
