The HEU250-108 is a Single output 24V DC 5A 120W model, and provides the control needed for precision power tasks. The 50HEU250-xy Series is a medically certified and compliant 250W Enclosed AC/DC Medical Power Supply (PSU). Designed for use in applications such as patient-connected monitoring and life-support devices.. This series is supplied with a Pin Connection input connection and supports input voltages of 85~264, ~, ~V AC 47~63Hz. Certified to UKCA, CE, cURus, CB, CCC, TUV, RoHS, REACH and compliant with IEC 60601-1/EN 60601-1/ES 60601-1/IEC 62368-1/EN 62368-1/UL 62368-1. This product range is built to meet the expectations of regulatory and healthcare professionals. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | Internal Power Supply (PSU) Enclosed Power Supplies |
---|---|
Input Voltage | 85~264V AC |
Output | 24V DC 5A |
Output Power | 120W |
Number of Outputs | Single |
Efficiency | 92.0% |
Output Connector | Pin Connection |
Dimensions | 121.6x63x40mm |
Industry | ITE, Audio & Video, Medical |
Standards | IEC 60601-1, EN 60601-1, ES 60601-1, IEC 62368-1, EN 62368-1, UL 62368-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
50HEU250-107 | 19V DC | 6.31A | 119.9W | Download Pdf | |
Compare |
50HEU250-110 | 36V DC | 3.33A | 119.9W | Download Pdf | |
Compare |
50HEU250-111 | 48V DC | 2.5A | 120W | Download Pdf | |
Compare |
50HEU250-109 | 30V DC | 4A | 120W | Download Pdf | |
Compare |
50HEU250-105 | 12V DC | 10A | 120W | Download Pdf | |
Compare |
50HEU250-106 | 15V DC | 8A | 120W | Download Pdf |
