DIN Rail Mount AC/DC Power Supply Converter56YSD100L-2404000

The YSD100L-2404000 is a Single output 24V DC 4A 96W model, and is a dependable choice for integrators and developers. The 56YSD100L-xy Series is a versatile and reliable 100W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as automation and control within IT and AV systems.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 50~60Hz. Certified to UKCA, CE, cULus, RoHS, REACH and compliant with UL 508/EN 62368-1/BS EN 62368-1. This product range is optimised for modern electronic designs - check out the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

DC Output Adjustable
High-Efficiency
Output Voltages: 5~24V DC
Protection: OLP, OVP, SCP
UL508, BS/EN 62368-1
Universal Input 90~264V AC / 120~370 V DC 50/60Hz

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC
Output	24V DC 4A
Output Power	96W
Number of Outputs	Single
Efficiency	86.0%
Output Connector	Terminal Block
Dimensions	55x100x92mm
Industry	ITE, Audio & Video
Standards	UL 508, EN 62368-1, BS EN 62368-1
