Enclosed DIN Rail Mount AC/DC Power Supply Converter56YSD100S-2404200

The YSD100S-2404200 is a Single output 24V DC 4.2A 100.8W model, and delivers product-level reliability where space and stability matter. The 56YSD100S-xy Series is a consistent and reliable 100W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as commercial AV, broadcasting and control panels.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is suitable for integration in a wide variety of electronic systems - view the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

100% Full load burn-in Test
3 Years Warranty
Class II Isolation
High-Efficiency
Protection: OLP, OVP, SCP
Universal Input 90~264V AC / 120~370 V DC 50/60Hz

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC
Output	24V DC 4.2A
Output Power	100.8W
Number of Outputs	Single
Efficiency	90.0%
Output Connector	Terminal Block
Dimensions	58x70x90mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
