Enclosed DIN Rail Mount AC/DC Power Supply Converter56YSD60S-2402500-RS

The YSD60S-2402500-RS is a Single output 24V DC 2.5A 60W model, and delivers the regulation and reliability designers look for. The 56YSD60S-xy-RS Series is a reliable and efficient 60W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as telecoms, computing and multimedia systems.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is built for integration into complex electronic environments - browse compatible options. If you can’t find what you need, contact us for alternative or tailored options.

Features

Output Voltages: 12~48V DCMeets the latest Safety Standards and ApprovalsHigh-Efficiency100% Full load burn-in TestLow Ripple & NoiseClass?Protection: Overload/Over voltage/Short circuit
Universal Input 90~264V AC 50/60Hz

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC
Output	24V DC 2.5A
Output Power	60W
Number of Outputs	Single
Efficiency	91.0%
Output Connector	Terminal Block
Dimensions	58x52x90mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
