Enclosed DIN Rail Mount AC/DC Power Supply Converter56YSD30S-2401250-RS

The YSD30S-2401250-RS is a Single output 24V DC 1.25A 30W model, and delivers clean power for small-scale electronic designs. The 56YSD30S-xy-RS Series is a high-quality and reliable 30W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.

Features

Output Voltages: 5~24V DCIEC/UL/EN 60950-1Meets the latest Safety Standards and ApprovalsHigh-Efficiency100% Full load burn-in TestLow Ripple & NoiseClass?Protection: Overload/Over voltage/Short circuit
Universal Input 90~264V AC 50/60Hz

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC
Output	24V DC 1.25A
Output Power	30W
Number of Outputs	Single
Efficiency	88.0%
Output Connector	Terminal Block
Dimensions	58x35x90mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
