Enclosed AC/DC Medical Power Supply (PSU)50HEU250-106

50HEU250-106

The HEU250-106 is a Single output 15V DC 8A 120W model, and delivers dependable performance where it matters most. The 50HEU250-xy Series is a medically certified and compliant 250W Enclosed AC/DC Medical Power Supply (PSU). Designed for use in applications such as patient-connected monitoring and life-support devices.. This series is supplied with a Pin Connection input connection and supports input voltages of 85~264, ~, ~V AC 47~63Hz. Certified to UKCA, CE, cURus, CB, CCC, TUV, RoHS, REACH and compliant with IEC 60601-1/EN 60601-1/ES 60601-1/IEC 62368-1/EN 62368-1/UL 62368-1. This product range is built to meet the expectations of regulatory and healthcare professionals. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Efficiency up to 93%
  • High Surge Immunity
  • Input to Output:2MOPP
  • Protection: OVP, OLP, OTP, SCP
  • Single Output from 12V to 48V
  • Wide Operating Voltage, 85 to 264VAC

Basic Specification

Product Type Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage 85~264V AC
Output 15V DC 8A
Output Power 120W
Number of Outputs Single
Efficiency 91.0%
Output Connector Pin Connection
Dimensions 121.6x63x40mm
Industry ITE, Audio & Video, Medical
Standards IEC 60601-1, EN 60601-1, ES 60601-1, IEC 62368-1, EN 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
50HEU250-107
50HEU250-107
19V DC 6.31A 119.9W Download Pdf
Compare
50HEU250-110
50HEU250-110
36V DC 3.33A 119.9W Download Pdf
Compare
50HEU250-111
50HEU250-111
48V DC 2.5A 120W Download Pdf
Compare
50HEU250-108
50HEU250-108
24V DC 5A 120W Download Pdf
Compare
50HEU250-109
50HEU250-109
30V DC 4A 120W Download Pdf
Compare
50HEU250-105
50HEU250-105
12V DC 10A 120W Download Pdf
