Enclosed AC/DC Power Supply 43TED100US15B

43TED100US15B

The TED100US15B is a Single output 15V DC 6.67A 100.05W model, and provides efficient output for modern electronics. The 43TED100-Uxy Series is a reliable and efficient 100W Enclosed AC/DC Power Supply (PSU). Designed for use in applications such as telecoms, computing and multimedia systems.. This series is supplied with a Metal input connection and supports input voltages of 85~264V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is built for integration into complex electronic environments - browse compatible options. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, CB, cURus, FCC, RoHS & REACH
  • EN/IEC/UL 62368-1 Safety Approved
  • High-Efficiency Rating up to 92%
  • Operating ambient temperature range: -40°C ~ +85°C
  • Output Voltage 12~48V DC
  • Universal Input 85~264V AC

Basic Specification

Product Type Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage 85~264V AC
Output 15V DC 6.67A
Output Power 100.05W
Number of Outputs Single
Efficiency 92.0%
Output Connector Pin Connection
Dimensions 3.6x2.44x1.54 "
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
43TED100US12B
43TED100US12B
12V DC 8.34A 100.08W Download Pdf
Compare
43TED100US24B
43TED100US24B
24V DC 4.17A 100.08W Download Pdf
Compare
43TED100US36B
43TED100US36B
36V DC 2.78A 100.08W Download Pdf
Compare
43TED100US28B
43TED100US28B
28V DC 3.58A 100.24W Download Pdf
Compare
43TED100US48B
43TED100US48B
48V DC 2.09A 100.32W Download Pdf
