DIN Rail Mount AC/DC Power Supply Converter56YDC60-40-138

The YDC60-40-138 is a Dual output 13.8V DC 1.9A 40.02W model, and provides the performance expected in trusted applications. The 56YDC60-xy Series is a consistent and reliable 60W DIN Rail Mount AC/DC Power Supply Converter. Designed for use in applications such as commercial AV, broadcasting and control panels.. This series is supplied with a Screw Terminal Block input connection and supports input voltages of 90~264V AC 50~60Hz. Certified to UKCA, CE, cULus, RoHS and compliant with UL 62368-1/BS EN 62368-1/EN 62368-1. This product range is suitable for integration in a wide variety of electronic systems - view the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

High-Efficiency up to 88%
Operating Temperature Range: -30°C~+70°C
Output SCP, OCP, OVP
Safety Standards to UL/EN/BS EN 62368-1
Voltage Input Range 90~264V AC or 127~370V DC
With built-in Battery charging circuit

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	90~264V AC
Primary Output	13.8V DC 1.9A
Secondary Output	13.8V DC 1A
Output Power	40W
Number of Outputs	Dual
Efficiency	86.0%
Output Connector	Terminal Block
Dimensions	41x1x92mm
Industry	ITE, Audio & Video
Standards	UL 62368-1, BS EN 62368-1, EN 62368-1
