U Chassis AC/DC Power Supply Module43MUD65UT63M6C

43MUD65UT63M6C

The MUD65UT63M6C is a Triple output 12V DC 3A 58.8W model, and offers clean, regulated power in demanding environments. The 43MUD65-Uxy Series is a medically regulated and dependable 65W U-Frame Chassis Mount AC/DC Medical Power Supply Converter. Designed for use in applications such as healthcare environments including hospitals and labs.. This series is supplied with a U Frame input connection and supports input voltages of 85~264, ~, ~V AC 47~63Hz. Certified to UKCA, CE, cURus, FCC, CB, RoHS, REACH and compliant with EN 60601-1/ES 60601-1/IEC 62368-1/EN 62368-1/UL 62368-1. This product range is suited for high-dependency applications where operational integrity is essential. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Efficiency up to 90.5%
  • EMC EN 60601-1-2, EN 55011, EN 55032 & FCC Class B Certified
  • Operating Temperature Range: -40°C~105°C
  • Safety standards to IEC/EN/UL 62368-1, ANSI/AAMI ES 60601-1
  • Single Output 5~53V DC
  • U Chassis Power Supply (PSU)Approved to UKCA, CE, CB, cURus, FCC
  • Universal Input 85~264V AC or 120~370V DC

Basic Specification

Product Type Internal Power Supply (PSU) U Frame Power Supplies
Input Voltage 85~264V AC
Primary Output 12V DC 3A
Secondary Output 5V DC 6A
Third Output -12V DC 0.6A
Output Power 58.8W
Number of Outputs Triple
Efficiency 89.0%
Output Connector SIP
Dimensions 2x3x1.36"
Industry ITE, Audio & Video, Medical
Standards EN 60601-1, ES 60601-1, IEC 62368-1, EN 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
43MUD65UT32M3C
43MUD65UT32M3C
5V DC 6A 46.8W Download Pdf
Compare
43MUD65UD03C
43MUD65UD03C
28V DC 1.25A 54.8W Download Pdf
Compare
43MUD65UD62C
43MUD65UD62C
12V DC 3A 55.8W Download Pdf
Compare
43MUD65UT32M6C
43MUD65UT32M6C
5V DC 6A 57W Download Pdf
Compare
43MUD65UT326C
43MUD65UT326C
5V DC 6A 57W Download Pdf
Compare
43MUD65UD32C
43MUD65UD32C
5V DC 6A 60W Download Pdf
Compare
43MUD65UT63M3C
43MUD65UT63M3C
12V DC 3A 63W Download Pdf
Compare
43MUD65UD63C
43MUD65UD63C
12V DC 3A 66W Download Pdf
Compare
43MUD65UD73C
43MUD65UD73C
15V DC 2.4A 66W Download Pdf
Compare
43MUD65UD93C
43MUD65UD93C
24V DC 1.5A 66W Download Pdf
Compare
43MUD65UT623C
43MUD65UT623C
12V DC 3A 69W Download Pdf
