96W AC/DC External Desktop Power Supply (PSU)66JYH5Z-xy-BY Series

66JYH5Z-xy-BY

The 66JYH5Z-xy-BY Series is a high-efficiency and standards-compliant 96W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as industrial control and automation systems.. This series is supplied with a IEC C14 input connection and supports input voltages of 100~240, ~, ~V AC 47~63Hz. Certified to cULus, UKCA, CE, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is perfect for manufacturers requiring efficient and adaptable power units. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to CE, cULus, RCM (C-Tick), RoHS & REACH
  • Class I (C14)
  • Meets Efficiency Level VI & (EU) 2019/1782
  • Single Output 12~48V dc
  • UL/EN/IEC 62368-1 Safety Approved
  • Universal Input 100~240V AC

Basic Specification

Product Type External Power Supply (PSU) Desktop Power Supply
Input Voltage 100~240V AC 47~63Hz
Output Power 96W
Number of Outputs Single
Input Connection IEC C14
Isolation 500V DC
Dimensions 140x60.5x33mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
66JYH5Z-1800530-BY-RS
66JYH5Z-1800530-BY-RS
18V DC 5.3A 95.4W Download Pdf
Compare
66JYH5Z-2400400-BY-RS
66JYH5Z-2400400-BY-RS
24V DC 4A 96W Download Pdf
Compare
66JYH5Z-4800200-BY-RS
66JYH5Z-4800200-BY-RS
48V DC 2A 96W Download Pdf
Compare
66JYH5Z-1200800-BY-RS
66JYH5Z-1200800-BY-RS
12V DC 8A 96W Download Pdf
Compare
66JYH5Z-1500640-BY-RS
66JYH5Z-1500640-BY-RS
15V DC 6.4A 96W Download Pdf
