50W AC/DC External Desktop Power Supply (PSU) 15DYS851-xxxyyyW Series

15DYS851-xxxyyyW

The 15DYS851-xxxyyyW Series is a safe and consistent, medically approved 50W AC/DC External Desktop Power Supply (PSU) . Designed for use in applications such as surgical, therapeutic and diagnostic machinery.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cURus, TUV, FCC, RCM (C-Tick), RoHS, REACH and compliant with EN 60601-1/IEC 60601-1/ES 60601-1. This product range is a reliable option for engineers specifying components for patient-use applications. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, TUV, cULus, RCM (C-Tick), FCC, RoHS & REACH
  • EMC Class B Certified
  • EN/IEC/ES 60601-1 Safety Approved
  • Meets Efficiency Level VI
  • OVP, OCP, OTP, SCP
  • Single Output 12~48V dc
  • Universal Input 100~240V AC

Basic Specification

Product Type External Power Supply (PSU) Desktop Power Supply
Input Voltage 90~264V AC 47~63Hz
Output Power 50W
Number of Outputs Single
Input Connection IEC C8
Dimensions 97.5x52.5x32.3mm
Industry Medical
Standards EN 60601-1, IEC 60601-1, ES 60601-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
15DYS851-120416W
15DYS851-120416W
12V DC 4.16A 49.9W Download Pdf
Compare
15DYS851-190265W
15DYS851-190265W
19V DC 2.65A 50.4W Download Pdf
Compare
15DYS851-240210W
15DYS851-240210W
24V DC 2.1A 50.4W Download Pdf
Compare
15DYS851-480105W
15DYS851-480105W
48V DC 1.05A 50.4W Download Pdf
