25W AC/DC External Desktop Power Supply (PSU)15DYS825-xyW-RS Series

The 15DYS825-xyW-RS Series is a medically certified and compliant 25W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as patient-connected monitoring and life-support devices.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, PSE, RoHS and compliant with EN 60601-1/IEC 60601-1. This product range offers system designers peace of mind with consistent, regulated output. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, PSE, RoHS
IEC/EN 60601-1 Safety Approved
Operating temperature 0~40°C
OVP, OCP, OTP, SCP
Single Output 5V DC
Universal input 90~264V DC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC 47~63Hz
Output Power	20W
Number of Outputs	Single
Input Connection	IEC C8
Dimensions	90.5x30.6x31.5mm
Industry	Medical
Standards	EN 60601-1, IEC 60601-1
