Home / External Power Supply (PSU) / Adapter Interchangeable Power Supply / 25HK-AB-xAz-CP6-1

Compare

30W AC/DC External Adapter Interchangeable Power Supply (PSU)25HK-AB-xAz-CP6-1 Series

The 25HK-AB-xAz-CP6-1 Series is a consistent and high-performing 30W AC/DC External Adapter Interchangeable Power Supply (PSU). Designed for use in applications such as embedded electronics and control equipment.. This series is supplied with a Interchangeable input connection and supports input voltages of 100~240V AC 47~63Hz. Certified to UKCA, cULus, CCC, FCC, TUV, RCM (C-Tick), CE, RoHS and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range has been designed to streamline your hardware development—contact us for product guidance. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, CCC, TUV, cULus, RCM (C-Tick), FCC, RoHS
FCC Class B Certified
IEC/EN 62368-1 Safety Approved
Meets Efficiency Level VI
OVP, OCP, OTP, SCP
Single Output 24V DC
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage	100~240V AC 47~63Hz
Output Power	30W
Number of Outputs	Single
Input Connection	Interchangeable
Dimensions	101x52x36mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
