Check out our range of power conversion series suitable for a vast range of applications.
.png)
Minimum order quantities apply on all of our products Please get in touch to see how we can support you on your next Power Supply Application project.
The DYS902-090750G is a Single output 9V DC 7.5A 67.5W model, and provides the performance expected in trusted applications. The 15DYS902-xyG Series is a durable and consistent 96W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as computing platforms and communications equipment.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is widely used in OEM, industrial, and AV platforms—explore the range. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | External Power Supply (PSU) Desktop Power Supply |
---|---|
Input Voltage | 90~264V AC |
Output | 9V DC 7.5A |
Output Power | 67.5W |
Number of Outputs | Single |
Output Connector | 2.5 x 5.5 x 11 mm |
Dimensions | 145x61.5x34mm |
Industry | ITE, Audio & Video |
Standards | EN 62368-1, IEC 62368-1, UL 62368-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
15DYS902-120750G | 12V DC | 7.5A | 90W | Download Pdf | |
Compare |
15DYS902-150600G | 15V DC | 6A | 90W | Download Pdf | |
Compare |
15DYS902-180500G | 18V DC | 5A | 90W | Download Pdf | |
Compare |
15DYS902-240400G | 24V DC | 4A | 96W | Download Pdf | |
Compare |
15DYS902-320300G | 32V DC | 3A | 96W | Download Pdf | |
Compare |
15DYS902-480200G | 48V DC | 2A | 96W | Download Pdf |
Our sales and technical team are just a click away.
