Home / External Power Supply (PSU) / Desktop Power Supply / 15DYS830-xyW-RS / 15DYS830-090300W-RS

Add to shortlist

Compare

AC/DC External Desktop Power Supply 15DYS830-090300W-RS

The DYS830-090300W-RS is a Single output 9V DC 3A 27W model, and delivers the regulation and reliability designers look for. The 15DYS830-xyW-RS Series is a versatile and reliable 30W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as automation and control within IT and AV systems.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, RoHS and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is optimised for modern electronic designs - check out the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC & RoHS
IEC/EN/UL 62368-1 Safety Approved
Operating temperature 0~40°C
OVP, OCP, OTP, SCP
Single Output 9V DC
Universal input 90~264V DC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC
Output	9V DC 3A
Output Power	27W
Number of Outputs	Single
Efficiency	86.6%
Output Connector	2.1 x 5.5 x 11 mm
Dimensions	90.5x49x31.5mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
