AC/DC External Adapter Interchangeable Power Supply 15DYS830-090300W-K-RS

The DYS830-090300W-K-RS is a Single output 9V DC 3A 27W model, and offers clean, regulated power in demanding environments. The 15DYS830-xyW-K-RS Series is a high-performance 30W AC/DC External Adapter Interchangeable Power Supply (PSU). Designed for use in applications such as digital signage, displays and user interfaces.. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), FCC, CCC, RoHS and compliant with EN 62368-1/IEC 62368-1. This product range supports critical performance in multimedia and IT hardware—see full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), FCC, CCC, RoHS
EMC Class B Certified
Interchangeable Power Supply
Meets Efficiency Level VI
OVP, OCP, OTP, SCP
Single Output 9V DC
UL/IEC/EN 62368-1 Safety Approved
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Plugtop AC/DC Power Supply
Input Voltage	90~264V AC
Output	9V DC 3A
Output Power	27W
Number of Outputs	Single
Output Connector	2.1 x 5.5 x 12 mm
Dimensions	76.8x47.5x35mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1
