AC/DC Lugged External Desktop Power Supply 59RKPO-UK0903500CD-4

The RKPO-UK0903500CD-4 is a Single output 9V DC 3.5A 31.5W model, and offers a steady output ideal for continuous-use systems. The 59RKPO-UKxxxxxxxCD-4 Series is a regulated and reliable 42W AC/DC Lugged External Desktop Power Supply (PSU). Designed for use in applications such as system-critical media and control infrastructure.. This series is supplied with a UK Mains Lead input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, RoHS and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is ideal for system builders and engineers - get in touch for technical support. If you can’t find what you need, contact us for alternative or tailored options.

Features

Dimensions: 130 x 51.5 x 39mm
IP68 Rated
Low Ripple & Noise
Operating Temperature Range: 0~40°
Output Voltages: 9~12V DC
Protection: Overload/Over voltage/Short circuit
Safety Approvals: UKCA, CE, TUV-GS, RoHS
Universal Input 90~264V AC 50/60Hz

Basic Specification

Product Type	External Power Supply (PSU) Lugged Desktop Power supply
Input Voltage	90~264V AC
Output	9V DC 3.5A
Output Power	31.5W
Number of Outputs	Single
Output Connector	Detachable 2.1 x 5.5 x 12 mm
Dimensions	130 x 51.5 x 39 mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
