The DYS836-075426W-K is a Single output 7.5V DC 4.26A 31.95W model, and offers a steady output ideal for continuous-use systems. The 15DYS836-xyW-K Series is a consistent and high-performing 40W AC/DC External Adapter Interchangeable Power Supply (PSU). Designed for use in applications such as embedded electronics and control equipment.. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range has been designed to streamline your hardware development—contact us for product guidance. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | External Power Supply (PSU) Adapter Interchangeable Power Supply |
---|---|
Input Voltage | 90~264V AC |
Output | 7.5V DC 4.26A |
Output Power | 32W |
Number of Outputs | Single |
Output Connector | 2.1 x 5.5 x 12 mm |
Dimensions | 84.5x52x35mm |
Industry | ITE, Audio & Video |
Standards | EN 62368-1, IEC 62368-1, UL 62368-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
15DYS836-050500W-K | 5V DC | 5A | 25W | Download Pdf | |
Compare |
15DYS836-090400W-K | 9V DC | 4A | 36W | Download Pdf | |
Compare |
15DYS836-240166W-K | 24V DC | 1.66A | 39.8W | Download Pdf | |
Compare |
15DYS836-300133W-K | 30V DC | 1.33A | 39.9W | Download Pdf | |
Compare |
15DYS836-150266W-K | 15V DC | 2.66A | 39.9W | Download Pdf | |
Compare |
15DYS836-180222W-K | 18V DC | 2.22A | 40W | Download Pdf | |
Compare |
15DYS836-120333W-K | 12V DC | 3.33A | 40W | Download Pdf |
