AC/DC External Desktop Power Supply 15DYS824-075282W-RS

15DYS824-075282W-RS

The DYS824-075282W-RS is a Single output 7.5V DC 2.82A 21.15W model, and delivers high compatibility with OEM build specs. The 15DYS824-xyW-RS Series is a high-performance 24W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as digital signage, displays and user interfaces.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, PSE, RoHS and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range supports critical performance in multimedia and IT hardware—see full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, PSE, RoHS
  • IEC/EN 62368-1 Safety Approved
  • Operating temperature 0~40°C
  • OVP, OCP, OTP, SCP
  • Single Output 5~24V DC
  • Universal input 90~264V DC

Basic Specification

Product Type External Power Supply (PSU) Desktop Power Supply
Input Voltage 90~264V AC
Output 7.5V DC 2.82A
Output Power 21.2W
Number of Outputs Single
Efficiency 85.7%
Output Connector 2.1 x 5.5 x 11 mm
Dimensions 90.5x30.6x31.5mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
15DYS824-050400W-RS
15DYS824-050400W-RS
5V DC 4A 20W Download Pdf
Compare
15DYS824-090250W-RS
15DYS824-090250W-RS
9V DC 2.5A 22.5W Download Pdf
Compare
15DYS824-090266W-RS
15DYS824-090266W-RS
9V DC 2.66A 23.9W Download Pdf
Compare
15DYS824-240100W-RS
15DYS824-240100W-RS
24V DC 1A 24W Download Pdf
