AC/DC External Adapter Interchangeable Power Supply (PSU)44MKB2-0502500DEXD-C

The MKB2-0502500DEXD-C is a Single output 5V DC 2.5A 12.5W model, and offers a steady output ideal for continuous-use systems. The 44MKB2-xy-DEXD-C Series is a medically regulated and dependable 12.5W Interchangeable AC/DC Plugtop Adapter Power Supply. Designed for use in applications such as healthcare environments including hospitals and labs. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, CB, cURus, FCC, RCM (C-Tick), SAA, RoHS, REACH and compliant with UL 60601-1/EN 60601-1/BS EN 60601-1. Engineered to align with evolving medical technology standards, this product range supports innovation in regulated healthcare systems. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, cULus, FCC, RCM (C-Tick), SAA, RoHS, REACH
Interchangeable Medical USB Plugtop Adapters
Protection: OCP, SCP
Safety standards to EN 60601-1/BS EN60601-1, AS NZS 60601-1
Supplied with UK, US, EU and AUS AC heads
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage	90~264V AC
Output	5V DC 2.5A
Output Power	12.5W
Number of Outputs	Single
Efficiency	80.0%
Output Connector	USB-C
Dimensions	59x41x34.5mm
Industry	Medical
Standards	UL 60601-1, EN 60601-1, BS EN 60601-1
