AC/DC External Adapter EURO USB Plugtop Power Supply 15DYS810-050210U-2-RS

15DYS810-050210U-2-RS

The DYS810-050210U-2-RS is a Single output 5V DC 2.1A 10.5W model, and offers consistent output for embedded systems. The 15DYS810-xyU-2-RS Series is a consistent and reliable 10.5W AC/DC External Adapter EURO USB Plugtop Power Supply (PSU). Designed for use in applications such as commercial AV, broadcasting and control panels.. This series is supplied with a EURO Fixed input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, RoHS and compliant with EN 62368-1/IEC 62368-1. This product range is suitable for integration in a wide variety of electronic systems - view the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, TUV-GS, RoHS
  • Direct Euro Fixed Plugtop Adapters
  • EMC Class B Certified
  • EN/IEC 62368-1 Safety Approved
  • OVP, OCP, SCP
  • Single Output 5V DC
  • Universal Input 90~264V AC

Basic Specification

Product Type External Power Supply (PSU) Adapter Plugtop AC/DC Power Supply
Input Voltage 90~264V AC
Output 5V DC 2.1A
Output Power 10.5W
Number of Outputs Single
Efficiency 79.0%
Output Connector USB A
Dimensions 65.4x23.5x37mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1
