Home / External Power Supply (PSU) / Desktop Power Supply / 15DYS890-xxxyyyG / 15DYS890-480200G

Add to shortlist

Compare

AC/DC External Desktop Power Supply 15DYS890-480200G

The DYS890-480200G is a Single output 48V DC 2A 96W model, and delivers the regulation and reliability designers look for. The 15DYS890-xxxyyyG Series is a consistent and reliable 96W AC/DC External Desktop Power Supply (PSU) . Designed for use in applications such as commercial AV, broadcasting and control panels.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), FCC, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is suitable for integration in a wide variety of electronic systems - view the full range. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), FCC, RoHS & REACH
EMC Class B Certified
Meets Efficiency Level VI
OVP, OCP, OTP, SCP
Single Output 12~48V dc
UL/IEC/EN 62368-1 Safety Approved
Universal Input 90~264V AC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC
Output	48V DC 2A
Output Power	96W
Number of Outputs	Single
Efficiency	88.0%
Output Connector	2.5 x 5.5 x 11 mm
Dimensions	2.5x5.5x11mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1
