AC/DC External Desktop Power Supply 25HK-AB-300A100-DH6-RS

The HK-AB-300A100-DH6-RS is a Single output 30V DC 1A 30W model, and provides a compact answer for regulated output needs. The 25HK-AB-xAz-DH6-RS Series is a performance-focused 30W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as network equipment and signal distribution hardware.. This series is supplied with a IEC C8 input connection and supports input voltages of 100~240V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, RoHS and compliant with EN 62368-1/UL 62368-1. This product range is suited for embedded use across IT, audio and visual sectors—view related products. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, cULus, RCM (C-Tick), RoHS & REACH
FCC Class B Certified
Meets Efficiency Level VI
OVP, OCP, OTP, SCP
Single Output 18~30V DC
UL/EN 62368-1 Safety Approved
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	100~240V AC
Output	30V DC 1A
Output Power	30W
Number of Outputs	Single
Efficiency	87.0%
Output Connector	2.1 x 5.5 x 12 mm
Dimensions	99x52x36mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, UL 62368-1
