AC/DC External Adapter Interchangeable Power Supply (PSU)44MKB2-1800800DEXD

44MKB2-1800800DEXD

The MKB2-1800800DEXD is a Single output 18V DC 0.8A 14.4W model, and delivers quality output expected from a professional-grade power supply unit. The 44MKB2-xy-DEXD Series is a compliant and stable 15W AC/DC External Adapter Interchangeable Power Supply (PSU). Designed for use in applications such as surgical, treatment and homecare equipment.. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, CB, cURus, FCC, RCM (C-Tick), SAA, RoHS, REACH and compliant with UL 60601-1/EN 60601-1/BS EN 60601-1. This product range has been developed for healthcare systems needing uninterrupted and stable performance. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to UKCA, CE, cULus, FCC, RCM (C-Tick), SAA, RoHS, REACH
  • Interchangeable Medical Plugtop Adapters
  • Protection: OCP, SCP
  • Safety standards to EN 60601-1/BS EN60601-1, AS NZS 60601-1
  • Single Output 3~24V DC
  • Supplied with UK, US, EU and AUS AC heads
  • Universal Input 100~240V AC

Basic Specification

Product Type External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage 90~264V AC
Output 18V DC 0.8A
Output Power 14.4W
Number of Outputs Single
Efficiency 84.0%
Output Connector 2.1x5.5x11.0mm
Dimensions 59x41x34.5mm
Industry Medical
Standards UL 60601-1, EN 60601-1, BS EN 60601-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
44MKB2-1201000DEXD
44MKB2-1201000DEXD
12V DC 1A 12W Download Pdf
Compare
44MKB2-0502500DEXD
44MKB2-0502500DEXD
5V DC 2.5A 12.5W Download Pdf
Compare
44MKB2-0901660DEXD
44MKB2-0901660DEXD
9V DC 1.66A 14.9W Download Pdf
Compare
44MKB2-0752000DEXD
44MKB2-0752000DEXD
7.5V DC 2A 15W Download Pdf
Compare
44MKB2-2400625DEXD
44MKB2-2400625DEXD
24V DC 0.625A 15W Download Pdf
