10VA AC/AC External Adapter US Plugtop Power Supply 77DB-10-18M

The DB-10-18M is a Single output 18V AC 0.56A W model, and delivers quality output expected from a professional-grade power supply unit. The 77DB-10-xy-M Series is a high-quality and reliable 10VA AC/AC External Adapter UK Plugtop Power Supply (PSU). Designed for use in applications such as commercial, industrial and OEM electronics.. This series is supplied with a UK Fixed input connection and supports input voltages of 230~240V AC 50Hz. Certified to UKCA, CE, TUV, RoHS, REACH and compliant with BS EN 61558-2-6/BS EN 61558-1. This product range is widely used in development and production across the AV and computing industry. If you can’t find what you need, contact us for alternative or tailored options.

Features

230~240V AC 50Hz Input
Approved to UKCA, CE, TUV, RoHS & REACH
BS EN 61558-2-6 & BS EN 61558-1 Safety Approved
Direct UK Fixed Plugtop Adapters
Meets Efficiency Level VI & (EU) 2019/1782
Output Current 0.56~1.1A
Output Voltage 9~18V

Basic Specification

Product Type	External Power Supply (PSU) Adapter Plugtop AC/AC Linear Power Supply
Input Voltage	230~240V AC
Output	18V AC 0.56A
Number of Outputs	Single
Efficiency	80.0%
Output Connector	6 Connectors Set
Dimensions	81.5x56.5x48.5mm
Industry	ITE, Audio & Video
Standards	BS EN 61558-2-6, BS EN 61558-1
