AC/DC Lugged External Desktop Power Supply 23SW-00150400-S10B-US

23SW-00150400-S10B-US

The SW-00150400-S10B-US is a Single output 15V DC 4A 60W model, and offers consistent output for embedded systems. The 23SW-xyz-S10B-US Series is a performance-focused 65W AC/DC Lugged External Desktop Power Supply (PSU). Designed for use in applications such as network equipment and signal distribution hardware.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is suited for embedded use across IT, audio and visual sectors—view related products. If you can’t find what you need, contact us for alternative or tailored options.

Features

  • Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
  • EMC EN 61000-3-2, EN 55032 Class B
  • Operating Temperature Range: 0~40°
  • OVP, OCP, OTP, SCP
  • Safety standards to IEC/EN/UL 62368-1
  • Single Output 9~24V DC
  • Universal Input 100~240V AC
  • US Plug Type

Basic Specification

Product Type External Power Supply (PSU) Lugged Desktop Power supply
Input Voltage 90~264V AC
Output 15V DC 4A
Output Power 60W
Number of Outputs Single
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 71.05x106.4x34.2mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
23SW-00090600-S10B-US
23SW-00090600-S10B-US
9V DC 6A 54W Download Pdf
Compare
23SW-00180330-S10B-US
23SW-00180330-S10B-US
18V DC 3.3A 59.4W Download Pdf
Compare
23SW-00120500-S10B-US
23SW-00120500-S10B-US
12V DC 5A 60W Download Pdf
Compare
23SW-00240271-S10B-US
23SW-00240271-S10B-US
24V DC 2.71A 65W Download Pdf
