The DYS865-150400W-RS is a Single output 15V DC 4A 60W model, and provides the performance expected in trusted applications. The 15DYS865-xyW-RS Series is a versatile and reliable 65W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as automation and control within IT and AV systems.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cULus, TUV, RCM (C-Tick), RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is optimised for modern electronic designs - check out the full range. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | External Power Supply (PSU) Desktop Power Supply |
---|---|
Input Voltage | 90~264V AC |
Output | 15V DC 4A |
Output Power | 60W |
Number of Outputs | Single |
Efficiency | 88.0% |
Output Connector | 2.1 x 5.5 x 12 mm |
Dimensions | 120x52.5x32mm |
Industry | ITE, Audio & Video |
Standards | EN 62368-1, IEC 62368-1, UL 62368-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
15DYS865-120500W-RS | 12V DC | 5A | 60W | Download Pdf | |
Compare |
15DYS865-240270W-RS | 24V DC | 2.7A | 64.8W | Download Pdf | |
Compare |
15DYS865-300216W-RS | 30V DC | 2.16A | 64.8W | Download Pdf | |
Compare |
15DYS865-180361W-RS | 18V DC | 3.61A | 65W | Download Pdf |
![]() |
RS | Product Code: 200-8935 |
