Check out our range of power conversion series suitable for a vast range of applications.
.png)
Minimum order quantities apply on all of our products Please get in touch to see how we can support you on your next Power Supply Application project.
The AK120WG-1200900W1 is a Single output 12V DC 9A 108W model, and delivers the regulation and reliability designers look for. The 14AK120WG-xy-W1 Series is a versatile and reliable 120W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as automation and control within IT and AV systems.. This series is supplied with a IEC C14 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, FCC, cULus, RCM (C-Tick), SAA, TUV-GS, PSE, CCC, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1. This product range is optimised for modern electronic designs - check out the full range. If you can’t find what you need, contact us for alternative or tailored options.
Product Type | External Power Supply (PSU) Desktop Power Supply |
---|---|
Input Voltage | 90~264V AC |
Output | 12V DC 9A |
Output Power | 108W |
Number of Outputs | Single |
Efficiency | 89.0% |
Output Connector | 3 Pin XLR |
Dimensions | 173x72.7x36mm |
Industry | ITE, Audio & Video |
Standards | EN 62368-1, IEC 62368-1, UL 62368-1 |
Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
---|---|---|---|---|---|---|
Compare |
14AK120WG-1500800W1 | 15V DC | 8A | 120W | Download Pdf | |
Compare |
14AK120WG-2400500W1 | 24V DC | 5A | 120W | Download Pdf | |
Compare |
14AK120WG-4800275W1 | 48V DC | 2.75A | 132W | Download Pdf |
![]() |
Digikey | Product Code: 2882-14AK120WG-1200900W1-ND |
