Home / External Power Supply (PSU) / Desktop Power Supply / 15DYS851-xyW-RS / 15DYS851-120416W-RS

Add to shortlist

Compare

AC/DC External Desktop Power Supply 15DYS851-120416W-RS

The DYS851-120416W-RS is a Single output 12V DC 4.16A 49.92W model, and delivers dependable performance where it matters most. The 15DYS851-xyW-RS Series is a compliant and stable 50W AC/DC External Desktop Power Supply (PSU). Designed for use in applications such as surgical, treatment and homecare equipment.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC, RoHS and compliant with EN 60601-1/IEC 60601-1. This product range has been developed for healthcare systems needing uninterrupted and stable performance. If you can’t find what you need, contact us for alternative or tailored options.

Features

Approved to UKCA, CE, TUV-GS, cULus, RCM (C-Tick), CCC, FCC & RoHS
IEC/EN 60601-1 Safety Approved
Operating temperature 0~40°C
OVP, OCP, OTP, SCP
Single Output 12~24V DC
Universal input 90~264V DC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC
Output	12V DC 4.16A
Output Power	49.9W
Number of Outputs	Single
Efficiency	88.0%
Output Connector	2.1 x 5.5 x 11 mm
Dimensions	97.5x32.3x52.5mm
Industry	Medical
Standards	EN 60601-1, IEC 60601-1
