AC/DC External Adapter Interchangeable Power Supply 40XA065BP1200300

The XA065BP1200300 is a Single output 12V DC 3A 36W model, and provides efficient output for modern electronics. The 40XA-065BP-xy Series is a high-efficiency and standards-compliant 65W AC/DC External Desktop Power Supply (PSU) . Designed for use in applications such as industrial control and automation systems.. This series is supplied with a IEC C8 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, cULus, TUV-GS, RoHS, REACH and compliant with UL 62368-1/EN 62368-1. This product range is perfect for manufacturers requiring efficient and adaptable power units. If you can’t find what you need, contact us for alternative or tailored options.

Features

EMC Class B Certified
Meets Efficiency Level VI & (EU) 2019/1782
Single Output 12V DC
UKCA, CE, cULus, TUV-GS, RoHS, REACH
UL/EN 62368-1 Safety Approved
Universal Input 90~264V AC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC
Output	12V DC 3A
Output Power	36W
Number of Outputs	Single
Efficiency	87.4%
Output Connector	2.1 x 5.5 x 12 mm
Dimensions	114x50x34mm
Industry	ITE, Audio & Video
Standards	UL 62368-1, EN 62368-1
