DC/DC ConvertersEncapsulated43RDL03-24D12W

The RDL03-24D12W is a Dual output 12V DC 0.0125A 1.65W model, and is a dependable choice for integrators and developers. The 43RDL03-xyzW Series is a reliable and performance-focused 3W DC/DC PCB Mount Power Supply. Designed for use in applications such as harsh, vibration-heavy or mobile rail environments.. This series is supplied with a SIP input connection and supports input voltages of 9~36, 18~75, 43~160V DC. Certified to UKCA, CE, cURus, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1/UL 62368-1/EN 50155. This product range has been chosen for its compliance with international rail standards. If you can’t find what you need, contact us for alternative or tailored options.

Features

4:1 Wide Input Range
Approved to IEC/UL/EN 62368-1
Approved to UKCA, CE, cURus
Efficiency up to 83%
EMC Class A & B Dependent on Input
Operating Temperature Range: -40°C~100°C
Single & Dual 3W Output Models
Small Size & Low Profile SIP8 Package 0.86 x 0.38 x 0.44"

Basic Specification

Product Type	DC/DC Converters DC/DC PCB Mount Power Supply
Input Voltage	9~36V DC
Primary Output	12V DC 0.0125A
Secondary Output	-12V DC -0.125A
Output Power	1.7W
Number of Outputs	Dual
Efficiency	82.0%
Output Connector	SIP
Dimensions	0.86x0.38x0.44"
Industry	ITE, Audio & Video, Railway
Standards	EN 62368-1, IEC 62368-1, UL 62368-1, EN 50155

Pdf Spec Sheet

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	43RDL03-110S3P3W	3.3V DC	0.7A	2.3W	Download Pdf
Compare	43RDL03-24S3P3W	3.3V DC	0.7A	2.3W	Download Pdf
Compare	43RDL03-48S3P3W	3.3V DC	0.7A	2.3W	Download Pdf
Compare	43RDL03-48D05W	5V DC	0.3A	3W	Download Pdf
Compare	43RDL03-48D12W	12V DC	0.125A	3W	Download Pdf
Compare	43RDL03-48D15W	15V DC	0.1A	3W	Download Pdf
Compare	43RDL03-48S05W	5V DC	0.6A	3W	Download Pdf
Compare	43RDL03-48S09W	9V DC	0.333A	3W	Download Pdf
Compare	43RDL03-48S12W	12V DC	0.25A	3W	Download Pdf
Compare	43RDL03-48S15W	15V DC	0.2A	3W	Download Pdf
Compare	43RDL03-48S24W	24V DC	0.125A	3W	Download Pdf
Compare	43RDL03-24D05W	5V DC	0.3A	3W	Download Pdf
Compare	43RDL03-24D15W	15V DC	0.1A	3W	Download Pdf
Compare	43RDL03-24S05W	5V DC	0.6A	3W	Download Pdf
Compare	43RDL03-24S09W	9V DC	0.333A	3W	Download Pdf
Compare	43RDL03-24S12W	12V DC	0.25A	3W	Download Pdf
Compare	43RDL03-24S15W	15V DC	0.2A	3W	Download Pdf
Compare	43RDL03-24S24W	24V DC	0.125A	3W	Download Pdf
Compare	43RDL03-110D05W	5V DC	0.3A	3W	Download Pdf
Compare	43RDL03-110D12W	12V DC	0.125A	3W	Download Pdf
Compare	43RDL03-110D15W	15V DC	0.1A	3W	Download Pdf
Compare	43RDL03-110S05W	5V DC	0.6A	3W	Download Pdf
Compare	43RDL03-110S09W	9V DC	0.333A	3W	Download Pdf
Compare	43RDL03-110S12W	12V DC	0.25A	3W	Download Pdf
Compare	43RDL03-110S15W	15V DC	0.2A	3W	Download Pdf
Compare	43RDL03-110S24W	24V DC	0.125A	3W	Download Pdf
