Range of 24V Lead Acid Battery Chargers31AC0724A

The AC0724A is a Single output 24V DC 7A 168W model, and delivers quality output expected from a professional-grade power supply unit. The 31ACXX24A Series is a high-efficiency and standards-compliant Range of 24V Lead Acid Battery Chargers. Designed for use in applications such as industrial control and automation systems.. This series is supplied with a IEC C14 input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, RoHS, REACH and compliant with EN 62368-1. This product range is perfect for manufacturers requiring efficient and adaptable power units. If you can’t find what you need, contact us for alternative or tailored options.

Features

24V Lead Acid 3 Stage Control (Fast/Normal/Float)
Aluminium Enclosure
Approved to UKCA, CE
LVD & EMC Class B Certified, RoHS & REACH compliant
OVP, OCP, OTP, SCP
Universal Input 100~240V AC

Basic Specification

Product Type	Battery Chargers Lead Acid
Input Voltage	90~264V AC
Output	24V DC 7A
Output Power	168W
Number of Outputs	Single
Output Connector	Crocodile Clips
Dimensions	180x88x47mm
Industry	ITE, Audio & Video
Standards	EN 62368-1
